MACHINE FOR SPECIAL MISSIONS MZURI PRO-TIL 4T
The Mzuri Pro-Til only cultivates narrow bands of soil, applies fertilisers across the entire depth of a strip to be tilled, places seeds at the controlled depths, provides the ideal environment for each group of seeds, and helps their fast germination and healthy growth, so the seeds can utilize their full potential.
Specification
Specification
Components
01Discs with hydraulically adjustable cutting depth
Each of the MZURI PRO TIL implements can be fitted with a set of cutting discs. The main role of this tool is to cut through excess crop residue and root systems of crops grown previously. This makes the single pass smooth without impeding the material flow. The working depth is controlled directly from the tractor cab. Each disc is spring-controlled to exert adjustable pressure as standard. The cutting sections come with a pivot system for easy continuous work in turns and on headlands.
02Reinforced wheels
A set of wheels for the Mzuri Pro-Til implements can incorporate reinforced tyres and wheel assembly with welded rims for increased resistance to stone impact. Buying the reinforced wheels will definitely extend your machine's life and eliminate the length of possible downtime.
03Optional fertiliser and seed hopper
The MZURI implements can be supplied with single (300 litres) or dual (2 x 300 litres) fertiliser and seed hoppers, e.g. for intercrop seeding. The dual applicator used in the machines allows the simultaneous seeding of two different products in separate doses. The applicator dosing units can be adjusted for seed placement either into the soil, onto its surface or into seed area.
04Central lubrication system
The central lubrication system is used in MZURI units to extend their life and reduce to a minimum the time to prepare a machine for work. MZURI units are designed to work in the heaviest soil conditions with high loads acting on working components, which are thus exposed to wear. You can keep your machines running efficiently by lubricating them regularly. Here, the central lubrication system comes to the rescue. It consists of an electric, programmable piston pump with a grease container, a set of distributors for dosing precisely the right amount of grease to each pin individually, a set of flexible supply hoses, and a tube for topping up the grease container.
MACHINES FOR SPECIAL MISSIONS
The Mzuri Pro-Til only cultivates narrow bands of soil, applies fertilisers across the entire depth of a strip to be tilled, places seeds at the controlled depths, provides the ideal environment for each group of seeds, and helps their fast germination and healthy growth, so the seeds can utilize their full potential.
Mzuri Pro-Til is designed as a machine for stubble fields, and it performs tillage, fertilisation and seeding in one pass. The tillage coulters and wheels are staggered alternately in two rows to leave large spaces for post-harvest residue to flow through. Each till and drill coulter is controlled independently by hydraulic arms to ensure accurate pressure applied on each section. This controlled pressure assures accurate depth and excellent contact of the seeds with soil.
The seed dosing unit uses variable speed electric motors that drive their respective seed rollers. A selection of seed rollers is provided to suit virtually all types of seeds. Calibration is straightforward and accurate – just press a button, weigh the collected seed and enter the amount on the control panel.
RDS Artemis adjusts the quantity of sown seeds on-the-move and provides all fertilisation and seed drill control and monitoring functions.
DOUBLE FRAME
The use of a double frame is a distinctive feature in the MZURI-PRO TIL range.
The first frame is used as a tilling section with an option for fertiliser application. This segment consists of independent, hydraulically-controlled pressure-adjustable subsoilers. During the drill, the tilling section applies fertilisers only onto the cultivated strips.
The second frame is used as a section for plant seed drilling. The seed drill arms fitted to this section are free to swivel sideways. This makes it possible to drill the seeds accurately into the strips cultivated by the subsoilers. Such a solution gives another advantage when the arms are protected from impacts. Similar to the tilling section, each seed drill arm is controlled hydraulically and comes with operating pressure adjustment.
The double-frame design enables both sections to operate at two independently adjustable depths.
MZURI PRO-TIL MAJOR FEATURES
- Tillage coulters controlled with hydraulic arms
- Variable seed metering unit
- Single and double row coulters
- Hydraulically driven fan
- Seed flow sensor
- Hydraulic bout marker
- Hydraulic adjustable harrow
- Semi-pneumatic seed dosing
- Artemis RDS drill management system
- Independently pivoting seeding arms, hydraulically operated, coupled with adjustable pressure wheels
